Authentication Overview

MinuteMenu uses three authentication mechanisms. Each serves a different purpose.

graph TB
    subgraph "User Authentication"
        UP["Username + Password<br/>(all products)"]
        SAML["SAML SSO<br/>(CX sponsors via Azure AD)"]
    end

    subgraph "Service Authentication"
        S2S["Basic Auth / API Keys<br/>(between services)"]
    end

    UP --> SSO[SingleSignOn Service]
    SAML --> SSO
    SSO --> Redis[(Redis<br/>Shared Sessions)]

    S2S --> HX_API[HX Cloud API]
    S2S --> KK_API[KK API]

    Redis --> KK[KidKare]
    Redis --> CX[Centers-CX]
    Redis --> PAR[Parachute]

The default authentication method. All products use it.

KidKare login — identifier-first flow (enter username, then password)

KidKare uses an identifier-first login. The user enters their username or email first, then the system determines whether to show a password field (standard) or redirect to a corporate IdP (SAML SSO).

How it works:

User enters username and password on login page
KK sends credentials to SingleSignOn Service (POST /auth)
SSO validates against its MySQL user database (salted hash)
If user doesn't exist in SSO but exists in HX or CX → account is created on the fly (JIT provisioning)
Session is stored in Redis, shared across all products
Session ID returned via cookie (ss-id header for SPA clients)

Session details:

Stored in Redis with 12-hour TTL
Shared across KK, CX, Parachute (same Redis instance)
Contains: user ID, roles, permissions, site data

Repos involved: KK (login UI + login types), SingleSignOn-Service (credential validation + session creation)

Added for CX (Center) sponsors who want their users to log in with corporate credentials via Microsoft Entra ID (Azure AD). Controlled by Policy A.13 per sponsor.

How it works (simplified):

User enters email on login page
System checks if the email domain is SSO-enabled (Home Realm Discovery)
If yes → redirect to corporate identity provider (Azure AD)
User authenticates at Azure AD
Azure sends SAML assertion back to SSO service
SSO validates assertion, creates a one-time exchange token
Redirects back to KK, which uses the token to create a normal session

Key characteristics:

Authentication only — user accounts and permissions still managed in KidKare
Policy-gated: each sponsor can enable/disable independently
Currently supports CX Sponsor and Center users only
SAML users have no KidKare password — they always log in via their IdP

Repos involved: KK (identifier-first UI, SAML BLL), SingleSignOn-Service (SAML callback, exchange token), MinuteMenu.Database (IdP config tables in CXADMIN)

See SAML SSO Architecture for the full technical flow.

3. Service-to-Service Authentication

Backend services authenticate with each other using Basic Auth or API keys. This is not user-facing but is critical for the Entra ID migration — every call site below depends on the current credential system.

How it works

Most service-to-service calls pass the user's BasicAuthHeader from their session. When a user logs in, their credential is stored in the Redis session. Every outbound call to another service re-uses that credential. A few services use hardcoded service accounts from app config instead.

graph LR
    subgraph "User Session (Redis)"
        BAH["BasicAuthHeader<br/>base64(user:password)"]
    end

    subgraph "KK Outbound"
        KK_RPT["KK → Report Engine"]
        KK_CX["KK → CX API"]
        KK_HOMES["KK → Homes API"]
        KK_PAR["KK → Parachute API"]
    end

    subgraph "Other Outbound"
        PAR_KK["Parachute → KK API"]
        CX_KK["Centers-CX → KK API"]
        HX_DCP["HX Cloud → DCP API"]
        HX_KK["HX Cloud → KK API"]
    end

    BAH --> KK_RPT
    BAH --> KK_CX
    BAH --> KK_HOMES
    BAH --> KK_PAR
    BAH --> PAR_KK
    BAH --> CX_KK

    CFG["Service Account<br/>(app config)"] --> HX_DCP
    RAW["RAW_PASSWORD table"] --> HX_KK

Complete Inventory

KK → Reporting Service (Basic Auth from user session)

The reporting service is the largest consumer of Basic Auth. Every report call passes the user's session credentials.

Caller Class	Repo	What it does
`ReportController` (~20 methods)	KK	PDF generation for homes, centers, sponsors — verify in/out times, payment details, child reports
`ReportService`	KK	ServiceStack report endpoints (legacy)
`CenterAccountingReportBll`	KK	Center accounting and financial reports
`CommonReportEnrollmentBll`	KK	Enrollment and income eligibility reports
`ProviderAccountingReportBll`	KK	Provider accounting and invoice reports
`ParachuteReportController`	KK	Parachute-specific reports
`SponsorController`	KK	Sponsor report operations
`MessageController`	KK	Message-related report operations
`AccountingReportService`	Parachute	FormW10 reports

KK → CX API (Basic Auth from session or CX DB)

Caller Class	Repo	What it does
`CentersClient`	KK	Attendance quantities, CX data operations
`CxIntegrationBll`	KK	FRP calculations, CX integration endpoints

Credentials come from the user session first. If unavailable, falls back to CX user password from CXADMIN database.

KK → Homes API (Basic Auth from user session)

Caller Class	Repo	What it does
`ReportController`	KK	Report data retrieval (ChildInOutTimes, PaymentDetails, etc.)

KK → Parachute API (Basic Auth from user session)

Caller Class	Repo	What it does
`ParachuteServiceRestClient` (factory)	KK	Multiple endpoints via HttpClient

Parachute → KK API (Basic Auth from user session)

Caller Class	Repo	What it does
`KidKareIntegrationBll` (6 methods)	Parachute	Cancel/reactivate fraud subscriptions, Zoho queries, coupon management
`KKServiceRestClient` (factory, used by 12+ classes)	Parachute	Attendance, Settings, UserReader, AccountingHelper, Notifications, ProviderHomeScreen, and more

Centers-CX → KK API (Basic Auth)

Caller Class	Repo	What it does
`EnrollmentsClient`	Centers-CX	Online enrollment counts by center/client
`ManageFoodClient`	Centers-CX	Food list auth links
`ManageArassfspClient` (2 methods)	Centers-CX	Claim and attendance management links
`RenewEnrollments`	Centers-CX	Completed online enrollments data
`IEFService`	Centers-CX	Income eligibility renewals
`Features`	Centers-CX	Online enrollment status, self-auth links

Note: CX has a SSO decision gate — Login.GetAzureComponent().IsAllowSupportOldSSO() switches between username:password and username:idToken. This is early migration scaffolding.

HX Cloud API → DCP (Hardcoded service credentials)

Caller Class	Repo	What it does
`DcpService` (4 methods)	hx_cloudconnectionAPI	Submit/analyze claims, get processing status. Uses username/password from `DcpOptionConfig`.

HX Cloud API → KK (Basic Auth from RAW_PASSWORD table)

Caller Class	Repo	What it does
`KKIntegration`	hx_cloudconnectionAPI	Callbacks to KK. Looks up raw password from `RAW_PASSWORD` table in DB.

Inbound Basic Auth (services that validate incoming Basic Auth)

Service	Repo	What it does
`AuthAttribute`	KK	Validates incoming requests — supports both session and Basic Auth header
`BasicAuthenticationFilterAttribute` on `ClaimsProcessingController`	DistributedProcessing	Validates incoming claims processing requests against configured service credentials

API Key / Other Auth

Route	Method	How
External → HX Cloud API	`mm-api-key` header (GUID)	Validated against `KK_API_KEY` table, exchanged for JWT
External → HX Cloud API	`x-api-key` header (encrypted)	Decrypted and validated, limited to specific endpoints
SSO → Azure APIM	SAS token (HMAC-SHA512)	Shared Access Signature for APIM management API
KK → Zoho	OAuth token	`Zoho-oauthtoken` header with refresh flow
KK → Stripe	Bearer token	Stripe API key as bearer
KK → Chat API	Bearer token	User token for chat/messaging
KK → ChargeBee	Basic Auth (API key)	ChargeBee API key encoded as Basic Auth

How They Connect

All three mechanisms ultimately produce the same result: a session in Redis that all products can read.

Username/Password ──► SSO validates ──► Redis session ──► KK, CX, Parachute
SAML SSO ──────────► SSO validates ──► Redis session ──► KK, CX, Parachute
Service-to-Service ► Direct auth ────► Request-scoped (no shared session)

Mechanism	Who uses it	Session shared?	Password in KidKare?
Username + Password	All users	Yes (Redis)	Yes
SAML SSO	CX sponsors with Policy A.13	Yes (Redis)	No — uses corporate IdP
Basic Auth / API Key	Backend services	No — per-request	N/A

Impact on Entra ID Migration

When migrating from MySQL-based auth to Azure Entra ID, every Basic Auth call site above needs to be addressed. Key considerations:

Category	Call Sites	Migration Impact
Session-based Basic Auth (user credential passthrough)	~30+ across KK, Parachute, CX	All depend on `BasicAuthHeader` stored in Redis session. If credentials change format (e.g., to tokens), every consumer breaks.
Reporting Service	~20 methods in KK alone	Largest single consumer. All use `UserSessionState.GetBasicAuthHeader()`.
Hardcoded service credentials	Rate Limiter, DCP Service	Independent of user auth — can migrate separately.
RAW_PASSWORD table	HX Cloud → KK callbacks	Stores plain passwords for Basic Auth encoding. Must be replaced.
CX SSO decision gate	6 clients in Centers-CX	Already has `IsAllowSupportOldSSO()` toggle — migration scaffolding exists.

Central points of change:

UserSessionState.GetBasicAuthHeader() — used by all session-based calls
ServiceClientExtension.UseBasicAuth() — extension method on all ServiceStack clients
EncryptionHelper.EncodeBasicAuthToken() / DecodeBasicAuthToken() — encoding/decoding utility
KKServiceRestClient factory in Parachute — factory for all Parachute → KK calls
